Goodman Furnace Error Codes List: Every Code Explained

Every Goodman furnace error code we could verify against Goodman's own documentation — what it means, what usually causes it, and the first fix to try — in one table. Codes differ between model series, so treat your model's tech sheet as the final word.

How to read and retrieve error codes on Goodman furnaces

Goodman boards keep the last faults readable via the display/LED, and newer models expose fault history through the CoolCloudHVAC app and the onboard menu. The fault chart on the blower door remains the authority — Goodman reused similar-looking codes across board generations.

The complete Goodman furnace error code list

How to reset / clear error codes on Goodman furnaces

Goodman furnaces report faults as LED blink patterns on older boards and as alphanumeric codes on the 7-segment displays of newer (and ComfortBridge/Bluetooth) models. Codes clear when the fault ends and a heat cycle completes; lockouts need the cause fixed plus a power cycle at the furnace switch.

How to diagnose any Goodman furnace code

Work the problem in this order — and stop at any point where gas, combustion or mains wiring is involved, because those belong to a licensed HVAC technician: (1) record the code exactly: count LED flashes slowly, twice, or photograph the alphanumeric display; (2) check the free things homeowners legitimately own: the thermostat is calling for heat, the furnace power switch and breaker are on, the filter is not clogged solid (a starved furnace overheats and locks out on limit codes), all vents and the return are open, and the condensate drain is not blocked on condensing models; (3) reset once — at the power switch, off for 30 seconds — then watch a full call for heat from the beginning: inducer, ignition, flame, blower, in that order; where the sequence stops is the fault family the code names; (4) a code that returns immediately is an active fault — do not keep resetting a lockout, especially any flame or limit code; (5) everything inside the burner compartment — flame sensor cleaning is the one grey area many manuals allow owners, but gas valves, burners, heat exchangers and control boards are professional work. If you smell gas at any point, leave and call the gas utility, not a helpline.

Blink codes, display codes and lockouts

Two generations of fault reporting live side by side on modern furnaces. Older and simpler boards report through a single LED: a repeating count of flashes, read slowly against the chart printed inside the blower door — that chart, for your exact model, outranks any list on the internet, including this one. Newer communicating furnaces show alphanumeric codes (the E-series in the table above) and store a fault history a technician can scroll. Both generations share the lockout idea: after a set number of failed attempts at the same step — ignition is the classic — the board stops trying for a period (often an hour, or until power is cycled) instead of cycling forever against a fault that could overheat or flood the burners with unburned gas. A furnace in lockout is not broken by the lockout itself; it is a furnace that has already failed the same step repeatedly and is waiting for someone to find out why.

Furnace codes are also seasonal in a way washer codes are not. The first cold snap produces a wave of ignition and flame codes from furnaces that sat idle all summer — oxidised flame sensors, spider-nested burners, pressure-switch hoses holding condensate from the cooling season. Deep-winter adds frozen condensate lines on high-efficiency models and intake/exhaust terminations blocked by snow or ice, which present as pressure-switch codes. A code that appears once, on the coldest night of the year, and never again has often met its cause already; a code that appears every cycle, in any weather, is a component asking to be tested.

The most searched Goodman furnace codes, in detail

9H — Not a Goodman fault code at all

This page exists because the display is genuinely confusing, so here is the documented picture. In the installation manual for Goodman's GM9S96 and GC9S96 furnaces, Goodman prints a "1 Stage Status Codes" table listing what the furnace's seven-segment display shows while it works: IdL for idle, FAn for continuous fan, 1AC and 2AC for cooling stages — and gH for "Gas heat – Single Stage Control." Those are status codes, the board narrating normal operation, and they share the display with the furnace's real fault codes. Rendered on a seven-segment display, a lowercase g is drawn with the same segments most people read as a 9, so gH becomes "9H" to almost every homeowner who looks at it — and two-stage models add a stage digit, which is why owners also report readings like 9h1 and 9h2 for low-stage and high-stage gas heat. Goodman's actual fault codes for this platform look completely different: they are the E- and EE-prefixed entries of the manual's troubleshooting chart (EE0 for ignition lockout, EE1 and EE2 for pressure-switch faults, and so on). No Goodman fault chart lists 9H, because nothing has failed when it shows. If your furnace displays 9H and the house is warming, the correct diagnosis is that the furnace is heating.

Most likely cause: A normal heat call is in progress — This is what gH means: the thermostat has called for heat and the board is running single-stage gas heat. The "cause" of 9H on the display is simply that your furnace is doing its job at the moment you looked at it.

First check: Start with the house, not the board: if warm air is coming from the registers and the temperature is holding or rising, 9H has already told you its whole story — the furnace is heating.

If it keeps coming back: 9H "keeps coming back" every time the furnace runs a single-stage heat call, for the life of the furnace — that is the design, not a relapse. The version of this worry that deserves attention is different: a furnace that shows normal statuses but cannot hold temperature, short-cycles, or starts adding EE chart codes alongside the statuses. Those changes, not the return of gH, are the signal to book a technician.

F02 — Not a Goodman code

If a search result, a forum post or a copied list sent you here looking for a Goodman furnace 'F02' error, the honest starting point is that Goodman has never published one. Two Goodman documents were read in full for this page. The installation instructions for Goodman's two-stage GCEC96/GMEC80 furnaces print a troubleshooting chart whose entire fault language is the red board LED: repeating flash counts (four flashes = open limit circuit, five = limit and rollout circuit open, six = pressure switch cycling lockout, seven = lockout after excessive ignition retries, eight = lockout after excessive flame recycles, and so on through twelve), a solid LED for an internal control fault, a rapid flash for a twinning error, and three double flashes for the second-stage pressure switch. There is no letter F in it. The modulating GMVM97's installation instructions print the second Goodman language — a character display with codes E0 (lockout from excessive ignition retries or flame recycles), E1 (low-stage pressure switch circuit closed at the start of the cycle), E2 (low-stage pressure switch circuit not closed), E3 (primary high limit open) and IF (integrated control internal fault) — mirrored at a ComfortNet thermostat only as a 'Call for Service' icon and a scrolling 'Check Furnace' message. Again, no F02. The wider Goodman families verified from Goodman manuals add E5 (open board fuse), E6 (weak flame signal), E7 (igniter circuit) and Ed (rollout switch open) on communicating models, and an EE-prefixed set (EE0-EE6, E11) on the newer R-32 models — still no F-family of fault codes. What does exist online is a set of third-party pages assigning 'F02' three mutually exclusive meanings — an ignition failure, a pressure-switch fault, a flame-detection fault — none of them citing a Goodman document, and contradicting each other, which is the signature of an invented code. Your furnace may well have a real fault; it is recorded in one of the two languages above, and the model number plus a careful reading will find it.

Most likely cause: An E-code misread as an F-code — On a small character display, Goodman's communicating E-codes are the closest real neighbours: E2 (the low-stage pressure switch circuit did not close) is the reading most easily copied down as 'F02' once a letter and a zero are supplied from memory. If your display actually shows E2, that code is real, documented, and diagnosed as a pressure-switch/draft fault — but it must be read off the display, not assumed from an 'F02' search.

First check: Read the rating plate first and write down the full model number (GMES80, GCEC96, GMVM97 and similar). Every real Goodman code is defined per model family, and the model decides which of the two languages — LED flashes or E-code display — your furnace speaks.

If it keeps coming back: If code-reading stays ambiguous after a careful video count, a technician reads the board's behaviour and the model's chart in minutes — bring the model number, the video, and the symptom sequence. A 'code' that no Goodman chart contains is itself useful information to hand over.

H6 — Not a Goodman fault code

Two mirror-image mistakes meet in this code. Goodman's installation manual for the GM9S96/GC9S96 generation lists gH — "Gas heat – Single Stage Control" — among its status codes: normal operating narration, not a fault. Read a seven-segment display from the wrong side, as happens when a board or display ends up inverted in downdraft and reoriented installations, and every character flips: the g that already passes for a 9 becomes a 6, the H drops to the front, and gH arrives at the eye as "H6." That is why no Goodman fault chart contains H6 — while the manual's troubleshooting chart is full of EE-prefixed faults. The same flip explains the longer strings owners search for. Read upside down, Goodman's EE0 becomes 033, and EE2 becomes 233 — so a furnace reported as "H6 033" is most likely showing a gas-heat status next to, or alternating with, a genuine EE0 fault, and Goodman's chart defines EE0 precisely: "Furnace lockout due to an excessive number of ignition retries (3 total) — failure to establish flame, or loss of flame after establishment." A "233" suffix points at EE2: "pressure switch circuit is not closed," with the chart sending diagnosis to the pressure-switch hose, a blocked flue or inlet pipe, a blocked drain system, or a weak induced-draft blower. Decode the orientation first; then, if a suffix is really there, the chart fault it decodes to is the diagnosis.

Most likely cause: An inverted display orientation — The root cause of H6 itself. Seven-segment characters are not rotation-proof: viewed upside down, gH (gas heat status) reassembles as H6, and EE-prefixed fault codes reassemble as digit strings like 033 and 233. Furnaces whose boards sit inverted in the blower compartment invite exactly this misread.

First check: Re-read the display the other way up before anything else: photograph it, rotate the photo 180 degrees, and see whether H6 becomes gH and any digits become EE codes — that single step resolves most H6 reports.

If it keeps coming back: H6 comes back as reliably as gH does — every heat call, forever — because it is the furnace's normal heating status seen from the wrong side. The decoded faults have their own recurrence logic: EE0 returns when an ignition or flame-sense weakness is still present, and EE2 is famous for cold-snap repeats, when a marginal drain blockage or a frost-narrowed flue termination tips a weak vent proof over the edge on the coldest nights.

5 Flashes — On Goodman's single-stage boards: flame sensed without the gas valve energised

Goodman's 5-flash is the clearest example on this site of why the door chart, not the flash count, is the diagnosis. Goodman publishes two residential board generations whose charts disagree at this number. On single-stage boards (the GMES80 generation), five flashes is a flame-safety report: the control is sensing flame with no call for heat and the gas valve not energised — Goodman's wording is 'flame sense without gas valve', and its verified cause list is a leaking gas valve, a lingering flame, or a shorted flame sensor signal. The furnace must not run on it: uncommanded flame and a lying safeguard are the same two bad stories as every other brand's version of this fault. On two-stage boards (the GMVC96/GCEC96 generation), five flashes belongs to a different system entirely — the limit circuit. Goodman's two-stage troubleshooting chart defines it as: limit and rollout circuit open for 15 minutes; open control board fuse or rollout switch. The control's internal logic, spelled out in Goodman's servicing text, is a timing ladder: when the limit circuit opens, the control first reports 4 flashes (open limit); if the circuit is still open past 5 minutes it assumes blower failure and reports 11 flashes; if it is still open past 15 minutes it concludes a manual-reset device — the rollout switch — or the board fuse has opened, reports 5 flashes, enters a one-hour lockout, and runs the inducer continuously. And on those same two-stage boards, where did flame-sensed go? To 1 flash ('flame sensed with no flame present'). Goodman's newest communicating and R-32 models render the flame fault in letters instead (EE4: flame detected when no flame should be present). So a Goodman owner with five flashes owns one of two completely different furnaces' worth of trouble — a gas-valve/flame problem or a rollout/fuse problem — and the first diagnostic act is not touching the furnace at all: it is establishing which board generation is flashing, from the model number and the chart inside the door.

Most likely cause: Leaking gas valve (single-stage flame branch) — Goodman's verified lead cause for flame-sensed: the valve passes gas it should hold back, so a genuine flame exists — or re-establishes — with the valve de-energised and no call for heat. The sensor is telling the truth; the valve's shutoff is what failed.

First check: FIRST, IDENTIFY THE BOARD: read the model number and the diagnostic chart inside the furnace door before interpreting the count. GMES80-generation (single-stage) chart: 5 flashes is the flame fault. GMVC96/GCEC96-generation (two-stage) chart: 5 flashes is rollout/fuse, and flame-sensed is 1 flash. Acting on the wrong generation's meaning is the standing error with this code — websites that print a single Goodman meaning for 5 flashes are mixing the two charts.

If it keeps coming back: A returning code means the unfixed branch is still talking. Flame branch returns sort by timing exactly as the sibling brands' do: after cycles (valve or lingering flame) versus at cold power-up (sensing chain). Two-stage returns mean the limit ladder is climbing again — watch for the 4-flash preamble on earlier cycles, which is the overheating story restarting — or the replacement fuse has met the same unfound short. In every case the return is information to hand the technician, recorded with its timing, not a prompt to reset harder.

Less common and model-specific codes

Search data shows owners also meet these codes on Goodman furnaces: 7P1, A11, B0, B1, B3, B4, E1C, ED8, F01, F03, F04, F09, F11, F4, F9, Fixes, Furnace, H9. They are not part of the core code list Goodman publishes for most models — several are series-specific, abbreviated display readings, or codes carried over from a sister platform — so we do not publish meanings for them rather than guess. Treat them by symptom: note what the machine was doing when the code appeared (filling, draining, heating, spinning), run one full power cycle (5 minutes off), and if the code returns, match the symptom to the closest documented family in the table above and check the tech sheet stored inside your machine for the model-specific definition.
